Single-row unshrouded pin header for board-to-board stacking
The 75160-125-36LF: It carries gold GXT mating finish on phosphor bronze square pins, rated 5 A and 110 V, with push-pull fastening and through-hole solder termination.
Amphenol ICC (FCI) BERGSTIK header, order code 75160-125-36LF, 36 positions, single row, 0.100" (2.54 mm) pitch, 5 A, 110 V, gold GXT mating finish, through-hole, solder termination.
$5.3745Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
- New & original stockTraceable channels only — no mixed lots, no re-taped reels.
- Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
- Photo-verified countsEvery line counted and photographed before the box closes.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Gender | Male Pin |
| Mounting type | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 110V |
| Current rating | 5A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 36 |
| Contact length - post | 0.125\" (3.18mm) |
| Overall contact length | 0.560\" (14.22mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.335\" (8.51mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What is the closest pin-compatible alternative to 75160-125-36LF in this BERGSTIK family?
No exact 36-position pin-compatible alternative is listed in the same series; the 75160-125-36LF is the 36-position variant.
