Amphenol ICC (FCI) BERGSTIK header, order code 75160-127-08LF, 8 positions, single row, 0.100" (2.54 mm) pitch, 5 A, 110 V, gold GXT mating contacts, through-hole, solder termination.
75160-127-08LF Amphenol ICC BERGSTIK Header, 8 Pos, 0.100"
MPN75160-127-08LF
Active
Amphenol ICC (FCI) BERGSTIK header, order code 75160-127-08LF, 8 positions, single row, 0.100" (2.54 mm) pitch, 5 A, 110 V, gold GXT mating contacts, through-hole, solder termination.
$1.3057Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 110V |
| Current rating | 5A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 8 |
| Contact length - post | 0.105\" (2.67mm) |
| Overall contact length | 0.465\" (11.81mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.260\" (6.60mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
