Amphenol BERGSTIK 75160-156-10LF Header, 10-Pos 2.54mm, 5A

MPN75160-156-10LF
Active

Amphenol BERGSTIK 75160-156-10LF, 10-position, 0.100" (2.54mm) pitch, single-row, unshrouded male pin header, through-hole solder, gold GXT 30µin plating, 5A, 110V, UL94 V-0.

$3.2652Ref. price · indicative, final on quote
75160-156-10LF datasheet
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

75160-156-10LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Operating temperature-65°C~130°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions10
Contact length - post0.120\" (3.05mm)
Overall contact length0.445\" (11.30mm)
Contact finish - matingGold, GXT™
Contact length - mating0.225\" (5.72mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

The Amphenol BERGSTIK 75160-156-10LF is a 10-position, single-row, unshrouded male pin header on the standard 0.100" (2.54 mm) pitch. It's a board-to-board interconnect — the unshrouded pins mate with a matching receptacle, and the through-hole solder tails lock into the PCB.

The 0.100" pitch matches the standard perf-board grid and lines up with common 0.100" IDC ribbon cable receptacles, though the unshrouded pins offer no keying, so orientation is on you during assembly. Overall contact length is 0.445" (11.30 mm), with a 0.225" (5.72 mm) mating pin and a 0.120" (3.05 mm) solder post.

Frequently asked questions

What is the recommended mating connector for 75160-156-10LF?

This unshrouded header mates with any standard 0.100" (2.54 mm) pitch female receptacle or socket strip that accepts a 0.025" square pin. The BERGSTIK series includes matching receptacles — confirm the position count and pitch match your BOM.

Can 75160-156-10LF be used with 2.54 mm ribbon cable?

Yes — the 0.100" (2.54 mm) pitch matches standard IDC ribbon cable. The unshrouded pins will mate with a 0.100" pitch IDC socket, but there is no polarization or latch, so the connection relies on the housing friction fit.
