BERGSTIK single-row right-angle header
The 75168-116-36LF is the 36-position member of Amphenol ICC's BERGSTIK unshrouded header line, a board-to-board interconnect in a through-hole right-angle orientation.
Amphenol BERGSTIK 75168-116-36LF Header, 36-Pos 2.54mm
MPN75168-116-36LF
Active
Amphenol BERGSTIK header, order code 75168-116-36LF, 36 positions, single row, 0.100" (2.54mm) pitch, gold GXT mating contacts, through-hole right-angle, solder termination, UL94 V-0.
$5.1072Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.110\" (2.79mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 36 |
| Contact length - post | 0.118\" (3.00mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.335\" (8.51mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
Where can I buy the 75168-116-36LF and get a price?
The 75168-116-36LF is orderable through this distributor.
What is the closest pin-compatible alternative in the BERGSTIK series?
No pin-compatible alternative is listed within the same series.
