Amphenol ICC (FCI) BERGSTIK header, order code 75168-119-18LF, 18 positions, single row, 0.100" (2.54mm) pitch, gold GXT mating contacts, through-hole right-angle, solder termination.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.110\" (2.79mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 18 |
| Contact length - post | 0.120\" (3.05mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.225\" (5.72mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 75168-119-18LF is the 18-position single-row member of the Amphenol ICC (FCI) BERGSTIK header line, unshrouded with a push-pull fastening type. Gold GXT plating on the mating contacts, rated UL94 V-0 thermoplastic insulation, and a 0.225" (5.72mm) mating length suit this header for board-to-board stacking where the pitch and row count match the receptacle.
The 75168-119-18LF is the only BERGSTIK header at 18 positions, single row, 2.54 mm pitch with gold GXT plating in the current record.
The insulation carries a UL94 V-0 flammability rating. RoHS and REACH compliance documentation is available from Amphenol ICC (FCI) upon request.
