75168-307-36LF — Amphenol product photo
Amphenol

75168-307-36LF BERGSTIK® Header, 36-Pos, 0.100" Pitch, Tin

MPN75168-307-36LF
Active

Amphenol ICC (FCI) BERGSTIK® series, 75168-307-36LF, unshrouded male pin header, 36 positions, 0.100" (2.54 mm) pitch, through-hole right-angle, tin-plated phosphor bronze contacts, UL94 V-0 thermoplastic housing.

$6.0339Ref. price · indicative, final on quote
75168-307-36LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

75168-307-36LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typePush-Pull
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.110\" (2.79mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions36
Contact length - post0.201\" (5.11mm)
Contact finish - matingTin
Contact length - mating0.225\" (5.72mm)
Contact finish thickness - mating78.7µin (2.00µm)

Product details

36-Position BERGSTIK® Header — Board-to-Board Fit

The 75168-307-36LF: All 36 positions are loaded, so the BOM position count matches the pin count directly. The through-hole, right-angle orientation places the pin row perpendicular to the PCB surface. This is the typical choice for board-edge mezzanine stacking or daughtercard connections where the cable or mating header routes parallel to the main board.

The mating contacts are tin-plated with a thickness of 78.7 µinch (2.00 µm). For higher cycle counts or corrosive environments, a gold-plated sibling in the BERGSTIK® family would be the better choice. The contact material is phosphor bronze, which provides good spring properties and corrosion resistance for the tin-plated interface.

The part is RoHS compliant per the 'LF' suffix in the order code.

Frequently asked questions

What is the pin count and pitch of 75168-307-36LF?

All positions are loaded.

Is 75168-307-36LF shrouded or unshrouded?

Unshrouded. It is an open pin header with no plastic shroud around the pins — mates with standard unshrouded receptacles.

What is the closest pin-compatible alternative to 75168-307-36LF?

No official cross-reference is listed. Within the BERGSTIK® series, a direct alternative would need 36 positions, single row, 0.100" pitch, unshrouded, through-hole right-angle, and tin-plated contacts. Gold-plated variants exist for higher cycle life but change the plating grade.
