Amphenol ICC (FCI) BERGSTIK® header, order code 75168-313-09, 9 positions, single row, 0.100" (2.54 mm) pitch, through-hole right-angle, tin-lead plated mating contacts, solder termination, unshrouded, UL94 V-0.
75168-313-09 Amphenol ICC (FCI) BERGSTIK® Header, 9 pos
MPN75168-313-09
Obsolete
Amphenol ICC (FCI) BERGSTIK® header, order code 75168-313-09, 9 positions, single row, 0.100" (2.54 mm) pitch, through-hole right-angle, tin-lead plated mating contacts, solder termination, unshrouded, UL94 V-0.
$0.7826Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.110\" (2.79mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 9 |
| Contact length - post | 0.136\" (3.46mm) |
| Contact finish - mating | Tin-Lead |
| Contact length - mating | 0.225\" (5.72mm) |
| Contact finish thickness - mating | 150.0µin (3.81µm) |
Product details
Frequently asked questions
What style and series does the 75168-313-09 belong to?
The 75168-313-09 is a Board to Board style header in the BERGSTIK® series from Amphenol ICC (FCI).
What is the closest pin-compatible alternative to the 75168-313-09?
The BERGSTIK® series includes many single-row unshrouded headers at 0.100" pitch — compare position count, plating, and mounting orientation against the BOM requirement.
