Amphenol ICC (FCI) BERGSTIK®, unshrouded header, 6 positions, 0.100" (2.54 mm) pitch, through-hole right-angle, tin-lead mating finish, UL94 V-0, obsolete.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.110\" (2.79mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 6 |
| Contact length - post | 0.120\" (3.05mm) |
| Contact finish - mating | Tin-Lead |
| Contact length - mating | 0.225\" (5.72mm) |
| Contact finish thickness - mating | 150.0µin (3.81µm) |
The 75168-319R06: The mating finish is tin-lead (150.0 µin / 3.81 µm thick), a legacy RoHS-exempt plating that provides good solderability and moderate corrosion resistance.
No direct replacement or successor is listed in the official record. Because this is an end-of-life part, availability is limited to independent distribution surplus.
No official replacement is recorded. A pin-compatible cross would need 6 positions, single row, 0.100" pitch, through-hole right-angle, unshrouded, with a mating pin length of 0.225" (5.72 mm).
