Amphenol ICC (FCI) BERGSTIK® unshrouded male pin header, 18 circuits, single row, 0.200" (5.08 mm) pitch, through-hole solder termination, 30.0 µinch GXT gold plating on mating surface, UL94 V-0 thermoplastic housing.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Gender | Male Pin |
| Mounting type | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.200\" (5.08mm) |
| Positions | 18 |
| Contact length - post | 0.135\" (3.43mm) |
| Overall contact length | 0.465\" (11.81mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 75188-102-18LF: Through-hole termination with a 0.135" (3.43 mm) post length provides a solid solder joint that resists mechanical stress from cable pulls, common in board-to-board interconnects where the header stays fixed on the PCB.
No official successor is listed under the 75188 base product number, so a direct pin-compatible drop-in replacement is not confirmed.
The 75188-102-18LF is obsolete and sourced through independent distribution. Submit an RFQ for a real-time sourcing check.
The pitch is 0.200" (5.08 mm) and the mounting type is through-hole solder. The header is unshrouded with a single row of 18 positions.
