Amphenol BERGSTIK® 75844-101-22LF Header, 22 Pos

MPN75844-101-22LF
Obsolete

Amphenol BERGSTIK® 75844-101-22LF, Header Breakaway, 22 Positions, 2 Rows, 0.100" (2.54mm) Pitch, Through Hole, Solder Termination, Gold GXT™ Mating Finish, 5A, 110V, UL94 V-0.

$3.2193Ref. price · indicative, final on quote
75844-101-22LF datasheet
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

75844-101-22LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Operating temperature-65°C ~ 130°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions22
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.100\" (2.54mm)
Overall contact length0.425\" (10.80mm)
Contact finish - matingGold, GXT™
Contact length - mating0.225\" (5.72mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

The Amphenol BERGSTIK® 75844-101-22LF is a 22-position, dual-row breakaway header on the standard 0.100" (2.54mm) pitch grid. The mating interface carries 30.0 µin (0.76 µm) of gold GXT™ over phosphor bronze, rated for 5 A per contact at 110 V.

Mating and Fit

This header mates with any standard 0.100" (2.54mm) pitch, dual-row, unshrouded female socket strip or IDC receptacle that accepts 0.025" square pins. The 0.225" (5.72mm) mating pin length provides adequate wipe for most standard socket strips.
