75844-128-72LF — Amphenol product photo
Amphenol

FCI 75844-128-72LF BERGSTIK® Header, 72 Pos, 0.100" Pitch

MPN75844-128-72LF
Active

FCI BERGSTIK® series, 75844-128-72LF, unshrouded breakaway header, 72 positions, 2 rows, 0.100" (2.54 mm) pitch, through-hole solder termination, male pin, Gold GXT™ contact finish 30.0 µin, 5 A, 110 V, UL94 V-0.

$11.2374Ref. price · indicative, final on quote
75844-128-72LF datasheet
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

75844-128-72LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Operating temperature-65°C~130°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBulk
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions72
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.165\" (4.19mm)
Overall contact length0.525\" (13.34mm)
Contact finish - matingGold, GXT™
Contact length - mating0.260\" (6.60mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

72-Position BERGSTIK® Breakaway Header for Dense Board-to-Board or Cable Interconnects

The FCI 75844-128-72LF is a 72-circuit, dual-row unshrouded breakaway header from the BERGSTIK® series, on the standard 0.100" (2.54 mm) pitch that dominates legacy and new board-level designs.

The 0.100" row-to-row spacing matches the industry-standard 0.100" x 0.100" grid, so the footprint drops onto a standard 72-pin, dual-row through-hole pattern with 0.100" pitch. The unshrouded design keeps the board-edge keep-out zone minimal — useful when routing traces close to the connector body.

Plating and Environmental Reach

No official cross-reference or direct substitute is on record, so the BOM line should be specced to this exact order code.

Frequently asked questions

Where can I buy 75844-128-72LF and what is the price?

Current pricing and stock availability are confirmed at quote time — submit your BOM quantity for a same-day quote.
