75844-150-12LF — Amphenol product photo
Amphenol

Amphenol 75844-150-12LF BergStik Header, 12 Pos, 2.54mm

MPN75844-150-12LF
Active

Amphenol BergStik® unshrouded breakaway header, 12 positions, 2 rows, 0.100" (2.54mm) pitch, through hole, solder termination, 5A, 110V, 30.0µin gold GXT mating finish.

$1.4600Ref. price · indicative, final on quote
75844-150-12LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

75844-150-12LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Operating temperature-65°C~130°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions12
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.123\" (3.12mm)
Overall contact length0.453\" (11.50mm)
Contact finish - matingGold, GXT™
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

BergStik Breakaway Header, 12 Positions, 0.100" Pitch

The Amphenol 75844-150-12LF is a 12-position, dual-row BergStik® unshrouded breakaway header. It uses the standard 0.100" (2.54mm) pitch on both the pin and row spacing, which matches the footprint of legacy 0.100" grid prototyping and production boards.

The through-hole termination with a 0.123" (3.12mm) solder tail suits wave-solder assembly on a standard 0.062" PCB — the tail length provides adequate through-board standoff without bottoming out on the solder side.

Within the same BergStik family, the 12-position 75844-150-12LF sits between the 10-position and 16-position variants. The 77313-818-12LF is a 12-position peer with 15.0µin gold mating finish — half the gold thickness of the 30.0µin on this part — which makes the 75844-150-12LF the better choice for applications requiring higher mating cycle endurance or a more corrosive environment.

Frequently asked questions

Where can I buy the 75844-150-12LF?

Submit your BOM quantity for a same-day quote.

What is the pitch and position count of the 75844-150-12LF?

This is a 12-position, dual-row header on a 0.100" (2.54mm) pitch, with the same 0.100" row spacing. The board footprint uses a standard 0.100" grid.

What is the closest functional alternative to the 75844-150-12LF?

The 77313-818-12LF is a 12-position BergStik peer with a 15.0µin gold mating finish — half the gold thickness of the 30.0µin on this part. The 75844-150-12LF is the better choice for higher mating cycle requirements or corrosive environments.
