75869-104 Obsolete 3M Quickie 20-Pin Shrouded Header

MPN75869-104
Obsolete

3M Quickie 75869-104, dual-row 20-position shrouded header, 0.100" (2.54mm) pitch, board-to-cable, through-hole solder, gold GXT 30µin mating finish, UL94 V-0, keying slot, Tube.

$1.7300Ref. price · indicative, final on quote
75869-104 datasheet
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

75869-104 Technical Specifications
ParameterValue
SeriesQuickie™
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Contact materialPhosphor Bronze
Insulation colorBlue
Insulation height0.377\" (9.57mm)
Insulation materialThermoplastic, Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageTube
FeaturesKeying Slot
ShroudingShrouded - 4 Wall
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions20
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.120\" (3.05mm)
Contact finish - matingGold, GXT™
Contact length - mating0.236\" (6.00mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

Obsolete status and sourcing path

The 75869-104 is officially classified as Obsolete. This means 3M no longer manufactures it, and no direct form-fit-function replacement has been published by the OEM. For BOM lines that still call out this order code, the sourcing path is through existing distributor stock or broker inventory. We can source it against an RFQ — confirm quantity and target price, and we will search available inventory across our supply network.

This header mates with a 20-position, dual-row, 0.100" pitch IDC socket or receptacle — the standard Quickie cable connector. Termination is through-hole solder. Confirm the board hole diameter for the 0.025" square pins before layout.

Frequently asked questions

How can I order the 75869-104 or check stock?

The 75869-104 is obsolete. We do not hold live stock figures on the page, but we can source it against an RFQ — submit your target quantity and we will check available inventory across our distributor and broker network. Pricing and lead time are confirmed at quote time.

What is the mating cable connector for 75869-104?

The mating half is a 20-position, dual-row, 0.100" pitch IDC socket or receptacle from the 3M Quickie series. The keying slot on this header means the receptacle must also have the corresponding keyway to mate.
