Board-to-board header, 72 circuits, right-angle mount
The 76345-104-72LF is the 72-circuit member of Amphenol ICC (FCI)'s BERGSTIK unshrouded header line, a board-to-board style connector with dual-row 0.100" (2.54mm) pitch.
Amphenol BERGSTIK 76345-104-72LF Header, 72 Pos, 2.54mm
MPN76345-104-72LF
Active
Amphenol ICC (FCI) BERGSTIK header, order code 76345-104-72LF, 72 positions, dual row, 0.100" (2.54mm) pitch, unshrouded, through-hole right-angle, solder termination, gold GXT mating contacts.
$8.0060Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.248\" (6.30mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 72 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.126\" (3.20mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.240\" (6.10mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What compliance documentation does Amphenol ICC (FCI) provide for the 76345-104-72LF?
RoHS and REACH compliance documentation is available from the manufacturer.
