Amphenol ICC (FCI) BERGSTIK® header, order code 76345-804-72LF, 72 positions, dual row, 0.100" (2.54mm) pitch, through-hole right-angle, gold GXT™ mating finish, solder termination.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.248\" (6.30mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 72 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.126\" (3.20mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.240\" (6.10mm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 76345-804-72LF: Mounts through-hole right-angle; solder termination.
Available through independent surplus channels. No pin-compatible drop-in replacement from the same series is documented.
No pin-compatible drop-in replacement from the same series is documented by the manufacturer. Evaluate other 0.100" pitch, 72-position, dual-row unshrouded headers from the BERGSTIK® family, but confirm footprint and pinout before ordering.
