Plating Grade and Contact Duty
The 76350-104-14LF: The mating surface carries 30.0 µinch (0.76 µm) of GXT gold over nickel — a thickness that supports several hundred mating cycles in a clean environment without exposing the base phosphor bronze.
76350-104-14LF BERGSTIK® Header, 14 Pos, 0.100" Pitch
MPN76350-104-14LF
Active
Amphenol ICC (FCI) BERGSTIK® series, 76350-104-14LF: 14-position unshrouded male pin header, 0.100" (2.54 mm) pitch, right-angle through-hole termination, 30.0 µinch GXT gold plating on the mating surface, UL94 V-0 thermoplastic housing.
$1.4562Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 14 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.120\" (3.05mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What is the pin count and pitch of the 76350-104-14LF?
The row spacing is also 0.100" (2.54 mm).
