Amphenol ICC (FCI) BERGSTIK header, order code 76350-303-22LF, 22 positions, dual row, 0.100" (2.54mm) pitch, through-hole right-angle, tin-plated mating contacts, solder termination, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Gender | Male Pin |
| Mounting type | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 22 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.095\" (2.41mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 78.7µin (2.00µm) |
The 76350-303-22LF is the 22-circuit member of the Amphenol ICC (FCI) BERGSTIK unshrouded header line, a through-hole right-angle board-to-board connector. It carries tin-plated square male pins on a 0.100" (2.54mm) pitch across two rows, with a 0.200" (5.08mm) insulation height and UL94 V-0 rated thermoplastic housing.
Amphenol ICC (FCI) provides RoHS and REACH compliance documentation for the 76350-303-22LF; the housing is rated UL94 V-0.
