Amphenol ICC (FCI) BERGSTIK® unshrouded header, 72 positions, 2 rows, 0.100" (2.54mm) pitch, through-hole right-angle, tin-plated male pins, UL94 V-0 black thermoplastic housing.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 72 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.120\" (3.05mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 78.7µin (2.00µm) |
The 76350-304-72LF: The mating interface uses tin plating at 78.7 µinch (2.00 µm) thickness on phosphor bronze contacts.
The base product number is 76350; variants in this family differ by plating, pin length, and position count.
The pitch is 0.100" (2.54mm) with 72 positions loaded across two rows. All positions are populated.
