Amphenol ICC (FCI) Dubox™ 76384-309LF, 9-position single-row shrouded header, 0.100" (2.54mm) pitch, through-hole solder termination, gold GXT™ mating finish, rated 3A, UL94 V-0, RoHS.
| Parameter | Value |
|---|---|
| Series | Dubox™ |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Friction Lock |
| Current rating | 3A |
| Operating temperature | -40°C~125°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.368\" (9.35mm) |
| Insulation material | Thermoplastic, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Cable/Wire |
| Package | Tube |
| Shrouding | Shrouded - 2 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 9 |
| Contact finish - post | Tin |
| Contact length - post | 0.134\" (3.40mm) |
| Overall contact length | 0.411\" (10.44mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.197\" (5.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 76384-309LF is a 9-position, single-row, shrouded header from Amphenol ICC's Dubox™ series. This is a wire-to-board connection: the header solders into the PCB and the mating half terminates the cable.
These dimensions define the board-to-mating-half standoff and the solder tail depth through the PCB.
It is RoHS compliant.
The 76384-309LF is an active part, sourced through independent distribution. Submit an RFQ for current pricing and availability — we confirm both at quote time.
Yes, it is RoHS Compliant.
