76385-308LF — Amphenol product photo
Amphenol

76385-308LF Amphenol ICC (FCI) Dubox™ Header, 16 Pos, 2.54mm

MPN76385-308LF
Active

Amphenol ICC (FCI) Dubox™, 76385-308LF, 16-position, 2-row, 0.100" (2.54mm) pitch, shrouded 2-wall header, through-hole solder termination, friction lock, gold GXT™ mating finish, 3 A, UL94 V-0.

$2.0100Ref. price · indicative, final on quote
76385-308LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

76385-308LF Technical Specifications
ParameterValue
SeriesDubox™
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typeFriction Lock
Current rating3A
Operating temperature-40°C~125°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.368\" (9.35mm)
Insulation materialThermoplastic, Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageTube
ShroudingShrouded - 2 Wall
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions16
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.134\" (3.40mm)
Overall contact length0.411\" (10.44mm)
Contact finish - matingGold, GXT™
Contact length - mating0.197\" (5.00mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

Board-to-Wire Fit: 16 Circuits, 2.54mm Pitch

Rated 3 A per contact, with 30.0 µinch (0.76 µm) gold GXT™ on the mating surface.

Sourcing and Compliance: Active, RoHS, UL94 V-0

No stock-holding claim — quantities are lot-specific and confirmed against your BOM quantity.

Position Count Choice: 14 vs 16 vs 20

The 76385-307LF carries 14 positions; the 76385-310LF carries 20 positions.

Frequently asked questions

What is the pinout of 76385-308LF?

The 76385-308LF is a 16-position, 2-row header with all positions loaded. Confirm the mating receptacle's keying and polarization before committing the harness.

Is 76385-308LF RoHS compliant?

Yes, the 76385-308LF is RoHS compliant.

How can I order 76385-308LF or check stock?

Sourced per RFQ; availability and current pricing confirmed at quote time.
