Amphenol ICC (FCI) Dubox header, order code 76385-314LF, 28 positions, dual row, 0.100" (2.54mm) pitch, 3 A, gold GXT™ mating contacts, through-hole, solder termination.
76385-314LF Amphenol ICC Dubox Header 28 Pos 2.54mm
MPN76385-314LF
Active
Amphenol ICC (FCI) Dubox header, order code 76385-314LF, 28 positions, dual row, 0.100" (2.54mm) pitch, 3 A, gold GXT™ mating contacts, through-hole, solder termination.
$2.5036Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Dubox™ |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Friction Lock |
| Current rating | 3A |
| Operating temperature | -40°C~125°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.368\" (9.35mm) |
| Insulation material | Thermoplastic, Glass Filled |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Cable/Wire |
| Package | Tube |
| Shrouding | Shrouded - 2 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 28 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.134\" (3.40mm) |
| Overall contact length | 0.411\" (10.44mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.197\" (5.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What is the mating style of 76385-314LF?
It is a board-to-cable/wire header with a shrouded 2-wall design and a friction lock for secure mating with the corresponding Dubox receptacle.
What compliance documentation is available for 76385-314LF?
RoHS and REACH compliance documentation is typically provided by Amphenol ICC (FCI) — consult the product datasheet or contact the manufacturer for specific certificates.
