Amphenol ICC (FCI) BERGSTIK® header, order code 77311-101-12, 12 positions, single row, 0.100" (2.54mm) pitch, 3A per contact, unshrouded, through-hole, solder termination, gold or GXT™ mating finish.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C ~ 125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 12 |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.095\" (2.41mm) |
| Overall contact length | 0.425\" (10.80mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 77311-101-12 is the 12-position single-row member of the Amphenol ICC (FCI) BERGSTIK® header line, an unshrouded through-hole board-to-board interconnect.
Stock is sourced from surplus and distributor inventory; availability and date codes are confirmed at RFQ.
Full RoHS and REACH status should be confirmed from the manufacturer's documentation for the specific date-code lot.
