Amphenol ICC (FCI) BERGSTIK header, order code 77311-871-15LF, 15 positions, single row, 0.100" (2.54 mm) pitch, unshrouded, through-hole solder termination, male pin, square contact, gold or GXT mating finish.
Amphenol BERGSTIK 77311-871-15LF Header, 15-Pos 2.54mm
MPN77311-871-15LF
Active
Amphenol ICC (FCI) BERGSTIK header, order code 77311-871-15LF, 15 positions, single row, 0.100" (2.54 mm) pitch, unshrouded, through-hole solder termination, male pin, square contact, gold or GXT mating finish.
$0.7998Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 15 |
| Contact finish - post | Tin |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
What is the flammability rating of the housing material?
The insulation material is thermoplastic rated UL94 V-0.
