Amphenol ICC (FCI) BERGSTIK header, order code 77311-887-36LF, 36 positions, single row, 0.100" (2.54mm) pitch, unshrouded, through-hole, solder termination, male pin, 3 A per contact.
Amphenol ICC BERGSTIK 77311-887-36LF Header, 36 Pos 2.54mm
MPN77311-887-36LF
Active
Amphenol ICC (FCI) BERGSTIK header, order code 77311-887-36LF, 36 positions, single row, 0.100" (2.54mm) pitch, unshrouded, through-hole, solder termination, male pin, 3 A per contact.
$2.2590Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 36 |
| Contact finish - post | Tin |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.495\" (12.57mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.275\" (6.99mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
What is the closest pin-compatible alternative in this series?
No same-series sibling at a different position count is listed as a pin-compatible alternative — the 77311-887-36LF is the 36-position variant; other BERGSTIK single-row headers share the 2.54 mm pitch but differ in position count and must match the circuit count on the board.
What compliance documentation is available?
RoHS and REACH compliance documentation is provided by Amphenol ICC (FCI) for the 77311 series.
