Amphenol ICC (FCI) BergStik®, unshrouded header, 34 positions, 2 rows, 0.100" (2.54 mm) pitch, through hole, solder termination, male square pins, 30.0 µin gold mating finish, tin post finish, UL94 V-0, black thermoplastic, bulk.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Gender | Male Pin |
| Mounting type | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 34 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.119\" (3.02mm) |
| Overall contact length | 0.724\" (18.40mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.505\" (12.83mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 77313-119-34: This header mates with unshrouded receptacles or female socket strips on the same pitch and row spacing.
There is no listed direct replacement from Amphenol ICC (FCI) — the base product number 77313 covers a range of BergStik headers, but no specific successor is documented. No stock-holding claim is made; sourced per request against the BOM quantity.
The 77313-119-34 is obsolete and not stocked on the shelf.
The base product number 77313 covers a family of BergStik headers, but no specific pin-compatible successor is documented. Buyers should confirm the BOM position count, pitch, and row spacing before selecting an alternative from the same series.
RoHS compliance is standard for the BergStik series, though no separate certificate is maintained on this listing. The contact finish is gold or GXT™ on the mating side and tin on the post — both materials are RoHS-compliant per typical industry practice.
