BERGSTIK breakaway header, 14 positions, 0.100" pitch
The 77313-119R14LF: It is unshrouded with a push-pull fastening system, through-hole mounting, and kinked-pin solder termination.
Contact material is phosphor bronze.
Amphenol BERGSTIK 77313-119R14LF Header, 14 Pos, 0.100"
MPN77313-119R14LF
Active
Amphenol ICC (FCI) BERGSTIK® header, breakaway, order code 77313-119R14LF, 14 positions, dual row, 0.100" (2.54 mm) pitch, 3 A per contact, unshrouded, through-hole, kinked-pin solder termination, gold or GXT™ mating contacts.
$1.0319Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Kinked Pin, Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 14 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.119\" (3.02mm) |
| Overall contact length | 0.724\" (18.40mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.505\" (12.83mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What is the style of this connector?
The style is Board to Board or Cable.
What compliance documentation does Amphenol ICC (FCI) provide for this part?
RoHS and REACH compliance documentation is available from the manufacturer upon request.
