Amphenol ICC (FCI) BERGSTIK® series, 68-position dual-row unshrouded header, 0.100" (2.54 mm) pitch, through-hole solder termination, 3 A per contact, 30.0 µinch gold mating finish, UL94 V-0 black thermoplastic housing.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 68 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.105\" (2.67mm) |
| Overall contact length | 0.465\" (11.81mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.260\" (6.60mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
When mated with a standard receptacle, the stack height is roughly the sum of the header's insulation height plus the receptacle's height — confirm the mated pair fits within your enclosure's z-height budget.
The base product number 77313 covers both variants, but the suffix -68LF indicates a lead-free (RoHS-compliant) finish.
The total mated stack height depends on the receptacle's body height and contact depth — measure the receptacle's mating face to board dimension and add the header's insulation height for the overall z-height.
Availability and current pricing confirmed at quote time.
