Amphenol ICC (FCI) BERGSTIK® header, order code 77313-158-48LF, 48 positions, dual row, 0.100" (2.54mm) pitch, 3A per contact, unshrouded, through-hole, solder termination, gold or GXT™ mating contacts.
Amphenol BERGSTIK 77313-158-48LF Header, 48 Pos, 2.54mm
MPN77313-158-48LF
Active
Amphenol ICC (FCI) BERGSTIK® header, order code 77313-158-48LF, 48 positions, dual row, 0.100" (2.54mm) pitch, 3A per contact, unshrouded, through-hole, solder termination, gold or GXT™ mating contacts.
$3.9482Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 48 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.790\" (20.06mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.570\" (14.47mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What is the closest pin-compatible alternative to the 77313-158-48LF in the BERGSTIK series?
No pin-compatible alternative is listed on record.
