Amphenol ICC (FCI) BERGSTIK header, order code 77313-402-12LF, 12 positions, dual row, 0.100" (2.54mm) pitch, 3A per contact, tin-plated mating and post contacts, through hole, solder termination.
Amphenol ICC (FCI) 77313-402-12LF BERGSTIK Header
MPN77313-402-12LF
Active
Amphenol ICC (FCI) BERGSTIK header, order code 77313-402-12LF, 12 positions, dual row, 0.100" (2.54mm) pitch, 3A per contact, tin-plated mating and post contacts, through hole, solder termination.
$0.5040Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 12 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.135\" (3.43mm) |
| Overall contact length | 0.465\" (11.81mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 78.7µin (2.00µm) |
Product details
Frequently asked questions
What is the closest pin-compatible alternative to 77313-402-12LF in the BERGSTIK family?
Within the BERGSTIK series, a 10-position (77313-402-10LF) or 14-position (77313-402-14LF) variant shares the same pitch, row spacing, and plating — match the position count to the circuit requirement.
