Active Production and Sourcing
The 77313-420-10LF: The part ships in bag packaging.
Mating and Termination Checklist
The 0.605" (15.37 mm) mating pin length provides good wipe length for reliable contact with standard receptacles.
77313-420-10LF Amphenol ICC BERGSTIK 10-Pin Header
MPN77313-420-10LF
Active
Amphenol ICC (FCI) BERGSTIK® 77313-420-10LF, 10-position dual-row unshrouded breakaway header, 0.100" (2.54 mm) pitch, tin-plated contacts, through-hole solder termination, rated 3 A per contact.
$0.5923Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 10 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.825\" (20.95mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.605\" (15.37mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 78.7µin (2.00µm) |
