77313-452-20LF BERGSTIK® Header, 20-Pin, 0.100" Pitch

MPN77313-452-20LF
Active

Amphenol ICC (FCI) BERGSTIK®, 20-position unshrouded breakaway header, 0.100" (2.54 mm) pitch, dual-row, through hole, tin-plated contacts rated 3 A per contact, UL94 V-0 black thermoplastic housing.

$1.1303Ref. price · indicative, final on quote
77313-452-20LF datasheet
StockContact for availability
Lead time3-5 Days wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

77313-452-20LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Current rating3A per Contact
Operating temperature-65°C~130°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions20
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.120\" (3.05mm)
Overall contact length0.594\" (15.09mm)
Contact finish - matingTin
Contact length - mating0.374\" (9.50mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating78.7µin (2.00µm)

Product details

20-Pin Unshrouded Breakaway Header

The 77313-452-20LF: Tin at this thickness handles moderate mating cycles — expect 50 to 100 cycles before wear-through, which suits one-time assembly or infrequent rework. The 3 A per-contact current rating is conservative for tin at 25 °C; derate above 85 °C ambient per the standard curve.

The base product number is 77313; the -452-20LF suffix specifies the 20-position, dual-row, tin-plated variant. No official pin-compatible replacement has been announced — if you need a shrouded or gold-plated version, look at other BERGSTIK® order codes in the same 0.100" pitch family.

Frequently asked questions

What is the pitch of the 77313-452-20LF header?

The mating pitch is 0.100" (2.54 mm), and the row spacing is also 0.100" (2.54 mm). That matches standard 0.100" grid PCB layouts.
