Amphenol ICC (FCI) BERGSTIK header, breakaway, order code 77313-801-26, 26 positions, dual row, 0.100" (2.54mm) pitch, through-hole, solder termination, gold or gold GXT™ mating contacts.
Amphenol ICC (FCI) 77313-801-26 BERGSTIK Header
MPN77313-801-26
Active
Amphenol ICC (FCI) BERGSTIK header, breakaway, order code 77313-801-26, 26 positions, dual row, 0.100" (2.54mm) pitch, through-hole, solder termination, gold or gold GXT™ mating contacts.
$0.7200Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 26 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.095\" (2.41mm) |
| Overall contact length | 0.425\" (10.80mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
Where can I buy 77313-801-26 and how do I get a price?
The 77313-801-26 is orderable under the listed part number. Request a quote for current pricing and lead time against the required quantity.
