Amphenol BERGSTIK 77313-801-52LF Header, 52-Pos 2.54mm

MPN77313-801-52LF
Active

Amphenol ICC BERGSTIK header, order code 77313-801-52LF, 52 positions, dual row, 0.100" (2.54mm) pitch, 3A per contact, gold flash mating contacts, through-hole, solder termination.

$1.8896Ref. price · indicative, final on quote
77313-801-52LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

77313-801-52LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Current rating3A per Contact
Operating temperature-65°C~130°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions52
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.095\" (2.41mm)
Overall contact length0.425\" (10.80mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating15.0µin (0.38µm)

Product details

Board-to-board or cable header

The 77313-801-52LF is the 52-position member of the Amphenol ICC BERGSTIK breakaway header line, suited for board-to-board or cable interconnect. Rated 3A per contact with gold flash on the mating surface and tin on the post, the header operates from -65°C to 130°C in a UL94 V-0 thermoplastic housing.

Unshrouded push-pull mating

The unshrouded design with push-pull fastening allows direct board stacking or cable mating without a locking latch — the 0.230" (5.84mm) mating pin length provides clearance for standard receptacles.
