Amphenol ICC (FCI) BERGSTIK® unshrouded breakaway header, order code 77313-G91-32LF, 32 positions, dual row, 0.100" (2.54mm) pitch, 3A per contact, through-hole solder termination, 30.0µin gold GXT™ mating finish.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 32 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.402\" (10.21mm) |
| Overall contact length | 0.724\" (18.40mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.220\" (5.59mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 77313-G91-32LF is the 32-circuit member of Amphenol ICC's BERGSTIK® unshrouded breakaway header line. It carries gold GXT™-plated square pins rated 3A per contact, mounts through-hole, and uses a push-pull fastening style with a UL94 V-0 black thermoplastic housing.
All positions are loaded.
