77317-102-72LF — Amphenol product photo
Amphenol

77317-102-72LF Amphenol ICC (FCI) BERGSTIK® Header, 72 Pos

MPN77317-102-72LF
Active

Amphenol ICC (FCI) BERGSTIK® header, order code 77317-102-72LF, 72 positions, dual row, 0.100" (2.54mm) pitch, 3A per contact, gold GXT™ mating contacts, through-hole right-angle, solder termination.

$4.7341Ref. price · indicative, final on quote
77317-102-72LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

77317-102-72LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader, Breakaway
Fastening typePush-Pull
Current rating3A per Contact
Operating temperature-65°C~130°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.190\" (4.83mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions72
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact finish - matingGold, GXT™
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

Breakaway header with gold GXT™ mating

The 77317-102-72LF: Through-hole right-angle orientation, UL94 V-0 thermoplastic housing.

Unshrouded push-pull fit for board stacking

The insulation height is 0.190" (4.83mm), so the mated stack height depends on the mating receptacle's profile. The breakaway design lets the assembler snap the 72-position strip to the exact circuit count needed — the board footprint and pitch are shared across the BERGSTIK® series, so a 36-position or 64-position segment uses the same contact system.

Frequently asked questions

What compliance documentation is available for 77317-102-72LF?

RoHS and REACH compliance documentation is available from Amphenol ICC (FCI) on request.
