Amphenol ICC (FCI) BERGSTIK header, order code 77317-817-20LF, 20 positions, dual row, 0.100" (2.54 mm) pitch, 3 A per contact, gold GXT mating contacts, through-hole right-angle, solder termination.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.190\" (4.83mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 20 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.063\" (1.60mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.295\" (7.49mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 77317-817-20LF is the 20-position member of Amphenol ICC's BERGSTIK breakaway header line, a dual-row unshrouded board-to-board style rated 3 A per contact. Gold GXT mating contacts with 15.0 µin (0.38 µm) plating and tin-plated posts suit repeated mating cycles in corrosive environments.
Mating pitch is 0.100" (2.54 mm) with identical row-to-row spacing, matching the standard 0.100" grid for board layout.
The header is rated UL94 V-0 for the thermoplastic housing. RoHS and REACH compliance documentation is provided by Amphenol ICC (FCI).
