Amphenol ICC (FCI) BERGSTIK® II, 78229-218HLF, 18-position unshrouded header, 0.100" (2.54 mm) pitch, male pin, through-hole press-fit, gold or GXT™ mating finish, black PCT housing, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Press-Fit, Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 18 |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.538\" (13.67mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 78229-218HLF: Termination is press-fit with solder — the through-hole post (0.120" / 3.05 mm long) can be press-fit into a plated-through hole for a gas-tight connection, or wave-soldered if the assembly line prefers. The housing is glass-filled PCT (UL94 V-0), rated for the flame resistance required in industrial control cabinets and telecom equipment.
The part ships in a bag (bulk packaging).
The 78229-218HLF is sourced through independent distribution against your RFQ. Submit a BOM quantity request for a current price and delivery estimate.
No surface-mount version is listed for this order code. The 78229-218HLF is a through-hole press-fit header. For SMT alternatives in the same series, check the BERGSTIK II product line for a different base number.
