Amphenol ICC (FCI) BERGSTIK® II header, order code 78548-222HLF, 22 positions, dual row, 0.100" (2.54 mm) pitch, gold or GXT™ mating contacts, through-hole, kinked pin solder termination.
78548-222HLF Amphenol ICC BERGSTIK II Header 22 Pos 2.54mm
MPN78548-222HLF
Active
Amphenol ICC (FCI) BERGSTIK® II header, order code 78548-222HLF, 22 positions, dual row, 0.100" (2.54 mm) pitch, gold or GXT™ mating contacts, through-hole, kinked pin solder termination.
$0.7239Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Polycyclohexylenedimethylene Terephthalate (PCT) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Kinked Pin, Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 22 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.538\" (13.67mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
What is the flammability rating of the housing?
The PCT insulation material is rated UL94 V-0.
