Amphenol ICC (FCI) BERGSTIK® II header, order code 78554-408HLF, 8 positions, single row, 0.100" (2.54mm) pitch, tin-plated mating contacts, through-hole right-angle, kinked pin solder termination.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.095\" (2.41mm) |
| Insulation material | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Kinked Pin, Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 8 |
| Contact finish - post | Tin |
| Contact length - post | 0.120\" (3.05mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The 78554-408HLF: Push-pull fastening and no shrouding mean the mating receptacle must provide its own alignment and retention. Housing is glass-filled PCT rated UL94 V-0, suited for equipment requiring a flame-rated insulator inside the enclosure.
The housing material is rated UL94 V-0. RoHS and REACH compliance documentation is provided by Amphenol ICC (FCI) for the BERGSTIK® II series.
