Amphenol ICC (FCI) BERGSTIK® II, 78938-436, unshrouded male pin header, 36 positions, 0.100" (2.54 mm) pitch, through-hole right-angle, tin-plated square pins, UL94 V-0 black housing.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.095\" (2.41mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 36 |
| Contact length - post | 0.120\" (3.05mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.120\" (3.05mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The 78938-436: This is a high-thickness tin finish — it handles moderate mating cycles (50–100) in a clean environment but will wear faster than gold under repeated connect/disconnect.
As part of the BERGSTIK® II series, this header shares the same pin pattern and pitch as the full range; the 36-position single-row variant is a dense option for parallel-board or right-angle interconnect.
Any standard 0.100" pitch unshrouded socket strip — no keying or latch. Confirm the mating half's pin count and row configuration match before committing.
