Amphenol ICC (FCI) BergStik® II header, order code 79257-430HLF, 30 positions, dual row, 0.100" (2.54mm) pitch, 3A, tin-plated mating contacts, through-hole right-angle, solder termination.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Gender | Male Pin |
| Mounting type | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C ~ 130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.190\" (4.83mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 30 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.120\" (3.05mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The 79257-430HLF is the 30-position member of the Amphenol ICC (FCI) BergStik® II unshrouded header line. Dual-row, 0.100" (2.54mm) pitch, tin-plated mating contacts rated 3 A, through-hole right-angle mounting with solder termination.
Available through distribution; submit an RFQ with the target quantity for a current price and lead time.
