79425-138HLF — Amphenol product photo
Amphenol

79425-138HLF BERGSTIK® II Header, 38 Pos, 0.100" Pitch, 5A

MPN79425-138HLF
Active

Amphenol BERGSTIK® II unshrouded header, 79425-138HLF, 38 positions, 2 rows, 0.100" (2.54mm) pitch, through-hole solder termination, 5A, 110V, 30µin gold mating finish, UL94 V-0.

$3.9706Ref. price · indicative, final on quote
79425-138HLF datasheet
StockIn Stock (20)
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

79425-138HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions38
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.120\" (3.05mm)
Overall contact length0.410\" (10.41mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.190\" (4.83mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

All 38 positions are loaded, giving you 19 pins per row for signal or low-current power distribution. Rated 5A per contact at 110V, with 30.0µin (0.76µm) gold or GXT™ plating on the mating surface. The phosphor bronze contacts and UL94 V-0 rated black insulation handle the thermal and flame requirements of equipment inside an enclosure.

Within the BERGSTIK® II family, the 79425-138HLF sits at 38 positions in a 2-row layout. The closest sibling in the same series is the 79425-136HLF at 36 positions — same 0.100" pitch, same dual-row footprint, same 5A rating. The decision between them is purely a circuit-count match to the BOM: the 38-position variant gives you two extra signal lines without changing the board layout pitch or the mating receptacle family.

Frequently asked questions

What is the price and availability of 79425-138HLF?

Submit your BOM quantity for a same-day quote.

What is the pitch of 79425-138HLF?

The pitch is 0.100" (2.54mm) on both the mating interface and the row spacing, matching the standard breadboard grid.

What connector mates with 79425-138HLF?

This unshrouded header mates with any standard 0.100" pitch dual-row female socket or IDC receptacle designed for 0.025" square pins — the same interface used across the BERGSTIK® II receptacle family.

Is 79425-138HLF RoHS compliant?

Yes, the 79425-138HLF is RoHS compliant as standard for the BERGSTIK® II series.
