86503-142HLF — Amphenol product photo
Amphenol

Amphenol BERGSTIK II 86503-142HLF Header, 42 Pos

MPN86503-142HLF
Active

Amphenol BERGSTIK® II, 42-position, dual-row, 0.100" (2.54mm) pitch, unshrouded male pin header, through-hole solder termination, 5A, 30µin gold plating.

$2.6069Ref. price · indicative, final on quote
86503-142HLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

86503-142HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions42
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.120\" (3.05mm)
Overall contact length0.470\" (11.94mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.250\" (6.35mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

The Amphenol BERGSTIK® II 86503-142HLF is a 42-position, dual-row unshrouded male pin header on the standard 0.100" (2.54mm) pitch. The square pins are phosphor bronze with a 30.0µin (0.76µm) gold or Gold, GXT™ mating finish, rated for 5A per contact at 110V.

The 0.100" pitch matches standard 2.54mm grid prototyping boards and common IC footprints, so board layout is straightforward. The 0.250" (6.35mm) mating pin length provides a solid engagement depth for the matching receptacle, while the 0.120" (3.05mm) solder tail is suited for standard 1.6mm PCBs.

This is typical for unshrouded headers used in board-to-board stacking where the mated pair is not subject to vibration or cable strain.

Frequently asked questions

What are the specifications of 86503-142HLF?

It is a 42-position, dual-row, unshrouded male pin header with 0.100" pitch, through-hole solder termination, 5A per contact, 110V rating, and 30µin gold plating on the mating surface. The insulation is black UL94 V-0 rated material.
