The Amphenol 86832-114HLF is a 14-position, dual-row unshrouded header from the BergStik II series. This is a board-to-board interconnect, through-hole soldered, with male square pins on a standard 0.100" (2.54mm) pitch — the same pitch that defines the BergStik II footprint for mating with the matching receptacle. The 14 positions are fully loaded, so the BOM position count matches the pin count directly. Rated 5 A per contact at 110 V, this header handles signal-level current for card-edge or mezzanine stacking applications. The UL94 V-0 rated black housing suits equipment inside an enclosure requiring flame rating.
What the Ratings Mean for Fit
The 0.100" pitch drives the board footprint — it matches the industry-standard BergStik II receptacle layout, so the board-side pattern is fixed. The 14 positions in two rows (7 per row) mean the connector spans 7 positions of 0.100" row spacing, which keeps the board area compact. The unshrouded design exposes the pins; there is no keying or polarization shroud, so the mating receptacle must be aligned correctly during assembly. The 30.0 µinch gold plating on the mating surface supports repeated mating cycles without contact resistance drift, making this header suitable for applications where the board may be removed and reinserted during service.
