Product Introduction
It uses a 0.100" (2.54 mm) square-pin grid on both pitch and row spacing, with all 12 positions loaded. Rated 5 A per circuit at 110 V, with 30.0 µ" (0.76 µm) gold plating on the mating surface over phosphor bronze contacts, this header suits moderate-duty signal and low-power distribution inside an enclosure.
Key Features and Ratings
The through-hole termination provides a stronger mechanical anchor than SMT for the same footprint, which matters when the header sees cable strain from the mating harness.
Applications and Environment
This unshrouded header is used as the board-mounted half of a connection inside equipment. The UL94 V-0 housing and 0.100" (2.54 mm) insulation height are specified.
