Amphenol ICC (FCI) Rib-Cage receptacle, order code 87024-640LF, 80 positions, dual row, 0.050" (1.27mm) pitch, female socket, square contact, surface-mount, solder termination, gold or GXT mating finish.
| Parameter | Value |
|---|---|
| Series | Rib-Cage™ |
| Type | Female Socket |
| Mounting | Surface Mount |
| Connector type | Receptacle |
| Fastening type | Push-Pull |
| Contact material | Beryllium Copper |
| Insulation color | Natural |
| Insulation height | 0.187\" (4.75mm) |
| Insulation material | Thermoplastic, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Tube |
| Parameter | Value |
|---|---|
| Features | Board Guide |
| Termination | Solder |
| Applications | General Purpose, Industrial, Telecommunications |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.050\" (1.27mm) |
| Positions | 80 |
| Row spacing - mating | 0.050\" (1.27mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 87024-640LF: Termination is surface-mount solder; the push-pull fastening type and integrated board guide assist alignment during assembly. The natural insulation color and 0.187" (4.75mm) insulation height are consistent across the Rib-Cage series.
Amphenol ICC (FCI) supplies the 87024-640LF.
