Amphenol ICC (FCI) BERGSTIK® II header, order code 87381-220H, 20 positions, dual row, 0.100" (2.54 mm) pitch, unshrouded male pin, through-hole solder termination, gold or GXT™ mating finish 15.0 µin (0.38 µm), UL94 V-0.
87381-220H Amphenol ICC (FCI) BERGSTIK® II Header, 20 Pos
MPN87381-220H
Obsolete
Amphenol ICC (FCI) BERGSTIK® II header, order code 87381-220H, 20 positions, dual row, 0.100" (2.54 mm) pitch, unshrouded male pin, through-hole solder termination, gold or GXT™ mating finish 15.0 µin (0.38 µm), UL94 V-0.
$2.3700Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
All specifications
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 20 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.100\" (2.54mm) |
| Overall contact length | 0.645\" (16.38mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.445\" (11.30mm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
Where can I buy the 87381-220H and get a price?
The 87381-220H is available through independent surplus channels. Submit a request for quote against the BOM quantity.
