87409-105LF Amphenol ICC (FCI) Rib-Cage™ III Header 10 Pos

MPN87409-105LF
Active

Amphenol ICC (FCI) Rib-Cage™ III, 87409-105LF, Board to Board Header, SMT, 10 Positions, 2 Rows, 0.050" (1.27mm) Pitch, Shrouded 4-Wall, 30µin Gold Mating Face, 1A DC, UL94 V-0, Active

$1.9900Ref. price · indicative, final on quote
87409-105LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

87409-105LF Technical Specifications
ParameterValue
SeriesRib-Cage™ III
GenderMale Pin
Mounting typeSurface Mount
Connector typeHeader
Fastening typePush-Pull
Current rating1A (DC)
Operating temperature-55°C~130°C
Insulation colorNatural
Insulation height0.226\" (5.74mm)
Insulation materialThermoplastic, Glass Filled
Mated stacking heights6.42mm
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageTube
FeaturesBoard Guide
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsGeneral Purpose, Military
Contact shapeSquare
Rows2
Pitch0.050\" (1.27mm)
Positions10
Row spacing - mating0.050\" (1.27mm)
Contact finish - postTin
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.130\" (3.30mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

Surface Mount Termination and Board Fit

The 87409-105LF: Surface mount termination (SMT) allows reflow assembly alongside other SMD components, eliminating a wave-solder step. The 1.27 mm pitch demands a precise solder-paste stencil aperture — the datasheet footprint shows a 0.60 mm pad width with a 0.30 mm solder mask opening to prevent bridging.

Comparing the 10-Position to the 20-Position Sibling

The 87409-110LF is the 20-position version of the same Rib-Cage™ III header — same pitch (0.050"), same stack height (6.42 mm), same gold plating (30 µinch), same 1 A DC rating. If your BOM needs more I/O on the same footprint pitch, the 20-position variant saves a second connector placement.
