Amphenol ICC (FCI) BERGSTIK® II, 87827-123HLF, unshrouded male pin header, 23 circuits, 0.100" (2.54mm) pitch, through-hole solder termination, 30.0µin gold mating finish, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 23 |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.380\" (9.65mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.160\" (4.06mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Overall contact length is 0.380" (9.65mm), split into a 0.160" (4.06mm) mating pin and a 0.120" (3.05mm) solder tail. The 0.100" (2.54mm) insulation height means the header sits low on the board — the mated stack height with a standard 2.54mm female socket is roughly 0.260" (6.6mm), give or take the socket's own height. This is common for low-cost board-to-board links where the mating connector is a simple female socket strip.
23 positions, all loaded, in a single row.
Yes, RoHS compliance is standard for this series.
Yes.
