Amphenol ICC (FCI) BERGSTIK® II unshrouded header, 6 positions, 0.100" (2.54mm) pitch, through-hole, tin-plated square pins, 3A, UL94 V-0, active production.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 6 |
| Contact finish - post | Tin |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.380\" (9.65mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.160\" (4.06mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
Classified as a board-to-board style connector with push-pull fastening and unshrouded pins — the bare pins rely on the mating receptacle's friction for retention, so the header is best used where the mated assembly is not subject to continuous vibration.
The pin pitch is 0.100" (2.54mm).
It is unshrouded — the square pins are exposed, so the mating receptacle provides the retention.
